SA 98-02 B5S

Installation Manual	Upper Mt. Ft   None Upper Mt. Rr   None
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -47.5  -1.87 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -27.5  -1.08 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  7.1  400  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4.8  270  - -
NOTES Sedan 4wd 6cyl.(Incl A4 2.8L)

Installation Manual	Upper Mt. Ft   None Upper Mt. Rr   None
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -32.5  -1.28 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -12.5  -0.49 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  6.7  370  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4.5  250  - -
NOTES Sedan 4wd 6cyl.(Incl A4 2.8L)

Without Pillowball Uppermount Installation Manual	Upper Mt. Ft   None Upper Mt. Rr   None
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -56  -2.2 -22.0 / -0.87 to -79.0 / -3.11 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -38  -1.5 -21.0 / -0.83 to -68.0 / -2.68
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  16  900  SB160-01200 +2.0 / 110.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  10  560  SW100-01175 +2.0 / 110.0 to -2.0 / -110.0
NOTES

Installation Manual	Upper Mt. Ft   None Upper Mt. Rr   None
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -56  -2.2 -22.0 / -0.87 to -79.0 / -3.11 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -38  -1.5 -21.0 / -0.83 to -68.0 / -2.68
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  16  900  SB160-01200 +2.0 / 110.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  10  560  SW100-01175 +2.0 / 110.0 to -2.0 / -110.0
NOTES
