TOYOTA  SUPRA 93-98 JZA80L
S.TECH
Upper Mt. Ft   None Upper Mt. Rr   None
EDFC Availability Not Available
Controller Kit Part No. -
Motor Kit Part No. -
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -28  -1.1 -
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -25  -0.98 -
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 12  670  - -
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 6.5  360  - -
NOTES


HIGH.TECH
Upper Mt. Ft   None Upper Mt. Rr   None
EDFC Availability Not Available
Controller Kit Part No. -
Motor Kit Part No. -
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -13  -0.51 -
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -10  -0.39 -
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 10.8  600  - -
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 5.9  330  - -
NOTES


Street Basis
Upper Mt. Ft   OEM Upper Mt. Rr   OEM
EDFC Availability Not Available
Controller Kit Part No. -
Motor Kit Part No. -
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -31  -1.22 +13.0 / +0.51 to -64.0 / -2.52
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -17  -0.67 +5.0 / +0.2 to -48.0 / -1.89
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 12  670  S8T60-01120 +0.0 / +0.0 to -0.0 / -0.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 7  390  S8T61-01070 +0.0 / +0.0 to -0.0 / -0.0
NOTES


Street Advance
Upper Mt. Ft   OEM Upper Mt. Rr   OEM
EDFC Availability Not Available
Controller Kit Part No. -
Motor Kit Part No. -
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -31  -1.22 +13.0 / +0.51 to -64.0 / -2.52
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -17  -0.67 +5.0 / +0.2 to -48.0 / -1.89
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 12  670  S8T60-01120 +0.0 / +0.0 to -0.0 / -0.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 7  390  S8T61-01070 +0.0 / +0.0 to -0.0 / -0.0
NOTES


TEIN BASIC Damper
Upper Mt. Ft   OEM Upper Mt. Rr   OEM
EDFC Availability Available
Controller Kit Part No. EDK04-K4469
Motor Kit Part No. EDK05-12120
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -27  -1.06 +10.0 / +0.39 to -55.8 / -2.2
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -17  -0.67 -6.0 / -0.24 to -39.14 / -1.54
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 14  780  SI140-01250 +2.0 / +110.0 to -2.0 / -110.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 8  450  SI080-01250 +2.0 / +110.0 to -2.0 / -110.0
NOTES


TEIN Super Street Damper
Without Pillowball Uppermount
Upper Mt. Ft   OEM Upper Mt. Rr   OEM
EDFC Availability Available
Controller Kit Part No. EDK04-K4469
Motor Kit Part No. EDK05-12120
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -27  -1.06 +10.0 / +0.39 to -55.8 / -2.2
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -17  -0.67 -6.0 / -0.24 to -39.14 / -1.54
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 14  780  SI140-01250 +4.0 / +220.0 to -2.0 / -110.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 8  450  SI080-01250 +2.0 / +110.0 to -2.0 / -110.0
NOTES


Type FLEX Damper
Upper Mt. Ft   P/U(Rigid) Upper Mt. Rr   P/U(Rigid)
EDFC Availability Available
Controller Kit Part No. EDK04-K4469
Motor Kit Part No. EDK05-12120
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -23  -0.91 +25.0 / +0.98 to -71.0 / -2.8
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -9  -0.35 +28.0 / +1.1 to -46.0 / -1.81
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 14  780  SL140-01200 +4.0 / +220.0 to -2.0 / -110.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 8  450  SI080-01250 +2.0 / +110.0 to -2.0 / -110.0
NOTES


Type CST Damper
Upper Mt. Ft   Rubber Upper Mt. Rr   Rubber
EDFC Availability Available
Controller Kit Part No. EDK04-K4469
Motor Kit Part No. EDK05-12120
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -14  -0.55 +23.0 / +0.91 to -38.0 / -1.5
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -6  -0.24 +22.0 / +0.87 to -25.0 / -0.98
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 10  560  SM100-01250 -
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 6  340  SK060-01300 -
NOTES
