240SX 95-98 S14

	Upper Mt. Ft   None Upper Mt. Rr   None
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -32  -1.26 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -24  -0.94 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3.8  210  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3.5  200  - -
NOTES

	Upper Mt. Ft   None Upper Mt. Rr   None
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -17  -0.67 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -9  -0.35 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3.2  180  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3.1  170  - -
NOTES

	Upper Mt. Ft   None Upper Mt. Rr   None
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -42  -1.65 -36.0 / -1.42 to -65.04 / -2.56 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -42  -1.65 -21.0 / -0.83 to -57.66 / -2.27
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  6  340  SL060-01200 +1.0 / +60.0 to -1.0 / -60.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  6  340  SI060-01250 +1.0 / +60.0 to -1.0 / -60.0
NOTES Wheel spacers may be required when the OEM wheel / tire size is used.

Without Pillowball Uppermount	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Available Controller Kit Part No. EDK04-K4469 Motor Kit Part No. EDK05-10120 Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -42  -1.65 -36.0 / -1.42 to -66.0 / -2.6 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -42  -1.65 -21.0 / -0.83 to -58.0 / -2.28
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  6  340  SL060-01200 +2.0 / +110.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  6  340  SI060-01250 +2.0 / +110.0 to -2.0 / -110.0
NOTES Wheel spacers may be required when the OEM wheel / tire size is used.

	Upper Mt. Ft   P/U(Adjustable) Upper Mt. Rr   P/U(Rigid)
	EDFC Availability Available Controller Kit Part No. EDK04-K4469 Motor Kit Part No. EDK05-12140 Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -30  -1.18 +8.0 / +0.31 to -69.0 / -2.72 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -39  -1.54 -10.0 / -0.39 to -69.0 / -2.72
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  6  340  SV060-01225 +2.0 / +110.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  5  280  SM050-01250 +2.0 / +110.0 to -2.0 / -110.0
NOTES Wheel spacers may be required when the OEM wheel / tire size is used.

	Upper Mt. Ft   P/U(Adjustable) Upper Mt. Rr   P/U(Rigid)
	EDFC Availability Available Controller Kit Part No. EDK04-K4469 Motor Kit Part No. EDK05-12140 Strut Kit Part No. EDK06-K4474
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -43  -1.69 -5.0 / -0.2 to -82.0 / -3.23 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -37  -1.46 -8.0 / -0.31 to -67.0 / -2.64
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  10  560  SQ100-01175 +2.0 / +110.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  8  450  SL080-01200 +2.0 / +110.0 to -2.0 / -110.0
NOTES Wheel spacers may be required when the OEM wheel / tire size is used.
