370Z 09+ Z34

	Upper Mt. Ft   None Upper Mt. Rr   None
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -22  -0.87 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -19  -0.75 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  8.5  480  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  9.4  530  - -
NOTES

	Upper Mt. Ft   P/U(Rigid) Upper Mt. Rr   Rubber
	EDFC Availability Available Controller Kit Part No. EDK04-K4469 Motor Kit Part No. EDK05-12120 Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -27  -1.06 +39.0 / +1.54 to -41.0 / -1.61 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -19  -0.75 +26.0 / +1.02 to -37.0 / -1.46
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  14  780  SL140-01200 +2.0 / +110.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  12  670  S6P93-0U120 +2.0 / +110.0 to 0 / 0
NOTES

	Upper Mt. Ft   P/U(Rigid) Upper Mt. Rr   Rubber
	EDFC Availability Available Controller Kit Part No. EDK04-K4469 Motor Kit Part No. EDK05-12120 Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -27  -1.06 +39.0 / +1.54 to -41.0 / -1.61 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -19  -0.75 +26.0 / +1.02 to -37.0 / -1.46
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  14  780  SL140-01200 +2.0 / +110.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  14  780  S6P93-0U140 0 / 0 to -2.0 / -110.0
NOTES
