GENESIS COUPE (4cyl) 10+ BK14

	Upper Mt. Ft   - Upper Mt. Rr   -
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -30  -1.18 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -30  -1.18 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  2.9  160  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  5.9  330  - -
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -33  -1.3 0 / 0 to -48.0 / -1.89 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -41  -1.61 -25.0 / -0.98 to -67.0 / -2.64
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  6  340  BD060-01225 +1.0 / +60.0 to -1.0 / -60.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  8  450  S6F13-0U080 +0.0 / +0.0 to -0.0 / -0.0
NOTES Mfg date (after 9/15/2010) require OEM Sway Bar Endlink. Part#54830-2M000.
