YARIS 07-10 NCP91L

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -53  -2.09 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -58  -2.28 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3  170  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3.5  200  - -
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -46  -1.81 -20.0 / -0.79 to -63.0 / -2.48 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -47  -1.85 -21.0 / -0.83 to -67.0 / -2.64
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  S8C16-01040 +0.0 / +0.0 to -0.0 / -0.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3.1  170  S5L71-01031 +0.0 / +0.0 to -0.0 / -0.0
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -52  -2.05 -26.0 / -1.02 to -69.0 / -2.72 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -55  -2.17 -43.0 / -1.69 to -75.0 / -2.95
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  S8C16-01040 +0.0 / +0.0 to -0.0 / -0.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3.1  170  S5L71-01031 +0.0 / +0.0 to -0.0 / -0.0
NOTES
