PRIUS 10+ ZVW30L

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -36  -1.42 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -38  -1.5 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  2.4  130  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3  170  - -
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -53  -2.09 -24.0 / -0.94 to -63.0 / -2.48 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -53  -2.09 -48.0 / -1.89 to -74.0 / -2.91
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  S8L98-01040 +1.0 / +60.0 to -0.0 / -0.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  S6Q09-01040 +1.0 / +60.0 to -0.0 / -0.0
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Available Controller Kit Part No. EDK04-K4469 Motor Kit Part No. EDK05-12120 Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -53  -2.09 -24.0 / -0.94 to -63.0 / -2.48 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -53  -2.09 -48.0 / -1.89 to -74.0 / -2.91
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  S8L98-01040 +1.0 / +60.0 to -0.0 / -0.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  S6Q09-01040 +1.0 / +60.0 to -0.0 / -0.0
NOTES

	Upper Mt. Ft   Rubber Upper Mt. Rr   OEM
	EDFC Availability Available Controller Kit Part No. EDK04-K4469 Motor Kit Part No. EDK05-12120 Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -53  -2.09 -35.0 / -1.38 to -75.0 / -2.95 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -49  -1.93 -34.0 / -1.34 to -70.0 / -2.76
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  JC040-0G225 +0.0 / +0.0 to -0.0 / -0.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  S6Q09-01040 +1.0 / +60.0 to -0.0 / -0.0
NOTES
