COROLLA 09+ AZE141L

	Upper Mt. Ft   - Upper Mt. Rr   -
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -40  -1.57 - REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -46  -1.81 -
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  3.5  200  - - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  4  220  - -
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -45  -1.77 -19.0 / -0.75 to -64.0 / -2.52 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -57  -2.24 -19.0 / -0.75 to -76.0 / -2.99
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  6  340  SB060-01200 +1.0 / +60.0 to -1.0 / -60.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  5.9  330  S8Q27-0U059 -
NOTES
