LANCER Evo V/VI 98-00 CP9A

	Upper Mt. Ft   P/U(Adjustable) Upper Mt. Rr   P/U(Rigid)
	EDFC Availability Available Controller Kit Part No. EDK04-K4469 Motor Kit Part No. EDK05-12140 Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -48  -1.89 -21.0 / -0.83 to -75.0 / -2.95 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -17  -0.67 +22.0 / +0.87 to -56.0 / -2.2
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  10  560  SL100-01200 +4.0 / +220.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  8  450  SL080-01200 +2.0 / +110.0 to -2.0 / -110.0
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  6  0.24 +20.0 / +0.79 to -2.0 / -0.08 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  9  0.35 +22.0 / +0.87 to +6.0 / +0.24
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  5.5  310  S9R10-01055 - REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  5.5  310  S9R11-01055 -
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -49  -1.93 -42.0 / -1.65 to -63.0 / -2.48 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  -9  -0.35 +16.0 / +0.63 to -29.0 / -1.14
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  14  780  RS140-B1200 +2.0 / +110.0 to -2.0 / -110.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  10  560  SL100-01200 +2.0 / +110.0 to -2.0 / -110.0
NOTES

	Upper Mt. Ft   OEM Upper Mt. Rr   OEM
	EDFC Availability Not Available Controller Kit Part No. - Motor Kit Part No. - Strut Kit Part No. -
RIDE HEIGHT FRONT Approx. Height Adjust Range mm inch Max/Min(mm/inch)  6  0.24 +20.0 / +0.79 to -2.0 / -0.08 REAR Approx. Height Adjust Range mm inch Max/Min(mm/inch)  9  0.35 +22.0 / +0.87 to +6.0 / +0.24
SPRING FRONT SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  5.5  310  S4R10-01055 0 / 0 to -0.5 / -30.0 REAR SPRING RATE / PART No. Replacement Availability kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)  5.5  310  SM055-01250 0 / 0 to -0.5 / -30.0
NOTES
