MITSUBISHI  LANCER Evo VII/VIII 03-05 CT9A
S.TECH
Upper Mt. Ft   None Upper Mt. Rr   None
EDFC Availability Not Available
Controller Kit Part No. -
Motor Kit Part No. -
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -51  -2.01 -
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -22  -0.87 -
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 3.8  210  - -
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 5.2  290  - -
NOTES


HIGH.TECH
Upper Mt. Ft   None Upper Mt. Rr   None
EDFC Availability Not Available
Controller Kit Part No. -
Motor Kit Part No. -
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -36  -1.42 -
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -7  -0.28 -
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 3.5  200  - -
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 4.8  270  - -
NOTES


TEIN BASIC Damper
Upper Mt. Ft   None Upper Mt. Rr   None
EDFC Availability Not Available
Controller Kit Part No. -
Motor Kit Part No. -
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -54  -2.13 -43.0 / -1.69 to -67.0 / -2.64
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -24  -0.94 -9.0 / -0.35 to -43.24 / -1.7
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 7  390  SV070-01225 +1.0 / +60.0 to -1.0 / -60.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 6  340  SV060-01225 +1.0 / +60.0 to -1.0 / -60.0
NOTES


TEIN Super Street Damper
Without Pillowball Uppermount
Upper Mt. Ft   None Upper Mt. Rr   None
EDFC Availability Available
Controller Kit Part No. EDK04-K4469
Motor Kit Part No. EDK05-12140
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -54  -2.13 -43.0 / -1.69 to -67.0 / -2.64
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -24  -0.94 -9.0 / -0.35 to -44.0 / -1.73
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 7  390  SV070-01225 +2.0 / +110.0 to -2.0 / -110.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 6  340  SV060-01225 +2.0 / +110.0 to -2.0 / -110.0
NOTES


Type FLEX Damper
Upper Mt. Ft   P/U(Adjustable) Upper Mt. Rr   P/U(Rigid)
EDFC Availability Available
Controller Kit Part No. EDK04-K4469
Motor Kit Part No. EDK05-12140
Strut Kit Part No. EDK06-K4474
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -52  -2.05 -22.0 / -0.87 to -72.0 / -2.83
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -33  -1.3 +11.0 / +0.43 to -78.0 / -3.07
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 12  670  SL120-01200 -
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 10  560  SL100-01200 -
NOTES


Super Racing Damper
Upper Mt. Ft   P/U(Adjustable) Upper Mt. Rr   P/U(Rigid)
EDFC Availability Available
Controller Kit Part No. EDK04-K4469x2
Motor Kit Part No. EDK05-12140(Compression) / EDK05-12120(Rebound)
Strut Kit Part No. EDK06-K4474(Compression) / -(Rebound)
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -57  -2.24 -32.0 / -1.26 to -77.0 / -3.03
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -39  -1.54 -2.0 / -0.08 to -90.0 / -3.54
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 12  670  RS120-B1175 -
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 10  560  RS100-A1175 -
NOTES


Type HG Damper
Upper Mt. Ft   OEM Upper Mt. Rr   OEM
EDFC Availability Not Available
Controller Kit Part No. -
Motor Kit Part No. -
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 0  0 +15.0 / +0.59 to -4.0 / -0.16
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 0  0 +13.0 / +0.51 to -4.0 / -0.16
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 6  340  S4R52-01060 +0.5 / +30.0 to -0.5 / -30.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 6  340  S4R53-01060 +0.5 / +30.0 to -0.5 / -30.0
NOTES
