LEXUS  LS400 95-00 UCF20
Type CS Damper
Upper Mt. Ft   Rubber Upper Mt. Rr   Rubber
EDFC Availability Available
Controller Kit Part No. EDK04-K4469
Motor Kit Part No. EDK05-12120
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -41  -1.61 -17.0 / -0.67 to -107.0 / -4.21
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -30  -1.18 -24.0 / -0.94 to -71.0 / -2.8
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 6  340  SK060-01300 +2.0 / +110.0 to -2.0 / -110.0
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 4  220  SK040-01300 +2.0 / +110.0 to -1.0 / -60.0
NOTES
