LEXUS  LS430 01-06 UCF30
Type CST Damper
Upper Mt. Ft   Rubber Upper Mt. Rr   Rubber
EDFC Availability Available
Controller Kit Part No. EDK04-K4469
Motor Kit Part No. EDK05-12120
Strut Kit Part No. -
FRONT  SIDE  REAR
RIDE HEIGHT
FRONT
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -33  -1.3 -8.0 / -0.31 to -55.0 / -2.17
REAR
Approx. Height Adjust Range
mm inch Max/Min(mm/inch)
 -32  -1.26 -21.0 / -0.83 to -50.0 / -1.97
SPRING
FRONT
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 6  340  SK060-01300 -
REAR
SPRING RATE / PART No. Replacement Availability
kgf/mm lbs/in Part # Max/Min(kgf/mm-lbs/in)
 4  220  S8003-01040 -
NOTES
